Mechanics
10 - English A26361-D1218-Z180-1-7619
Fan 2 connector
(system fan - supervised)
1
Pin Signal
1 GND
2 +12 V
3 Fan sense
Wake On LAN (WOL) connector
1
Pin Signal
1 VCC Auxiliary
2 GND
3 Wake pulse (high asserted)
USB port - Dual channel
12
Pin Signal
Pin Signal Pin Signal
1 VCC Dual (max. 250mA) 2 VCC Dual (max. 250mA)
3 Reserved 4 Key
5
Power supply on
(max 1 second low pulse)
6 GND
7 Data positive 8 Data negative
9 GND 10 Over current (low asserted)
11 Key 12 Key
13 Key 14 Key
15 VCC Dual (max. 250mA) 16 VCC Dual (max. 250mA)
17 Key 18 Key
19 Power supply on
(max 1 second low pulse)
GND
21 Data positive Data negative
22 GND Over current (low asserted)
