Documentation
A26361-D1218-Z180-1-7619 English - 15
Power
Power requirement
Source Voltage Maximum variation Maximum current Comment
Main power supply +5.0 V ±5 % 15 A
Main power supply +12 V ±10 % 350 mA
Main power supply -12 V ±10 % 200 mA
Main power supply +3.3 V ±5 % 4 A
Auxiliary power supply +5.0 V ±5 % 2 A
Power loadability
Fuse
number
Maximum fuse
current
Function Maximum function current
1 750 mA Keyboard port Not specified
Mouse port Not specified
Game port Not specified
VGA connector Minimum 50 mA
2 500 mA Universal serial bus (USB) Port A 500 mA
3 500 mA Universal serial bus (USB) Port B 500 mA
Documentation
Ê Insert the "Drivers & Utilities" CD.
Ê If the CD does not start automatically, run the START.EXE file in the main directory of the CD.
Ê Select your system board or your device.
Ê Select Documentation.
Ê Select - Technical Manuals
Ê Select - Technical Manuals (BIOS)
i
You may have to install the Acrobat Reader - Software on the CD-ROM
(path: utls/acrobat) before reading!
For more details please read the according readme.txt files.
Installing drivers
Ê Insert the "Drivers & Utilities" CD.
Ê If the CD doesn't start automatically call the START.EXE file in the main directory of the CD.
Ê If the system board list is displayed select the system board or select under Driver the
operating system used and the audio and video drivers.
