Startup
8
Cinch socket
SPDIF IN
SPDIF Out
yellow Digital sound
connection
see also manual on
the motherboard and
"Tips and tricks"
USB socket
or
USB
black
white
Connection for USB
2.0 devices (e.g.
keyboard, IR
sender/receiver
module, scanner,
printer) USB 2.0
3)
or
FireWire socket
IEEE 1394
black
white
Connection for IEE-
compatible devices
(e.g. video recorder,
digital camera)
FireWire
RJ-11 socket
or
or LINE
or PHONE
none
Modem
RJ-45 socket
or
or LAN
none
Network or DSL
modem
Antenna socket
CATV none
Cable, antenna
connection
4-pole or more
socket
SVIDEO IN
SVIDEO OUT
black
Video input and
output connection
(see documentation
about the VGA/TV
card)
SPDIF
optic
black
Digital optical sound
connection
● LED WLAN LINK green WLAN operational
display
DVI white
Connection for digital
video signal (monitor)
