3 Rack Configuration and Installation 115
E
3.1.4 Model 2616
*1) Ensure that the floor load based on the total rack capacity does not exceed the floor strength
(withstand load) at the installation site (such as an office).
*2) Key operation is required for locking the door handle.
Item Specifications
Product name 19-inch rack Model 2616 base rack
Type name 19R-261A2
Appearance Coated black (front and rear doors with punched metal finish)
Unit mounting capacity 16 U
Size (W x D x H) [mm] 600 x 1050 x 845
Maximum weight-bearing
load [kg]
Total rack capacity: 387kg (*1)
Total load capacity: 320kg (excluding rack)
Rack: 67kg
Door opening ratio 75%
Accessories
Items already attached to the rack when shipped
・ Front door, rear door, and a pair of side covers
Items in their own packages when shipped with the rack
・ Rack door key: 2 (*2)
・ Cable holder (front): 4
・ Cable holder (rear): 4
・ M5 flat head screw and core spring nut: 8 of each (for cable holder)
・ Cage nut tool
・ User's Guide (CD): 1 set
