3.1.5 Model 2624
*1) Ensure that the floor load based on the total rack capacity does not exceed the floor strength
(withstand load) at the installation site (such as an office).
*2) Key operation is required for locking the door handle.
Item Specifications
Product name 19-inch rack Model 2624 base rack
Type name 19R-262A2
Appearance Coated black (front and rear doors with punched metal finish)
Unit mounting capacity 24 U
Size (W x D x H) [mm] 600 x 1050 x 1200
Maximum weight-bearing
load [kg]
Total rack capacity: 559kg (*1)
Total load capacity: 480kg (excluding rack)
Rack: 79kg
Door opening ratio 80%
Accessories
Items already attached to the rack when shipped
・ Front door, rear door, and a pair of side covers
Items in their own packages when shipped with the rack
・ Rack door key: 2 (*2)
・ Cable holder (front): 6
・ Cable holder (rear): 6
・ M5 flat head screw and core spring nut: 12 of each (for cable holder)
・ Cage nut tool
・ User's Guide (CD): 1 set
