3 Rack Configuration and Installation 117
E
3.1.6 Model 2642
*1) Ensure that the floor load based on the total rack capacity does not exceed the floor strength
(withstand load) at the installation site (such as an office).
*2) The expansion rack is not equipped with a pair of side covers.
*3) Key operation is required for locking the door handle.
*4) The expansion rack is supplied without the User's Guide (CD).
The base rack can be connected to an expansion rack, and the expansion rack can be
connected to another expansion rack. These racks cannot be connected to Model 2737 and
2742 racks and other series racks.
Item Specifications
Product
name
19-inch rack Model 2642 base rack 19-inch rack Model 2642 expansion rack
Type name 19R-264A2 19R-264B2
Appearance Coated black (front and rear doors with punched metal finish)
Unit
mounting
capacity
42 U
Size
(W x D x H)
[mm]
600 x 1050 x 2000
Maximum
weight-
bearing
load [kg]
Total rack capacity: 954kg (*1)
Total load capacity: 840kg (excluding rack)
Rack: 114kg
Total rack capacity: 928kg (*1)
Total load capacity: 840kg (excluding rack)
Rack: 88kg
Door
opening
ratio
80%
Accessories
Items already attached to the rack when shipped
・ Front door, rear door, and a pair of side covers ・ Front and rear doors (*2)
Items in their own packages when shipped with the rack
・ Rack door key: 2 (*3)
・ Cable holder (front): 10
・ Cable holder (rear): 10
・ M5 flat head screw and core spring nut: 20 of each
(for cable holder)
・ Cage nut tool
・ Protection bushing: 2
・ User's Guide (CD): 1 set
・ Rack door key: 2 (*3)
・ Cable holder (front): 10
・ Cable holder (rear): 10
・ M5 flat head screw and core spring nut: 20 of each
(for cable holder)
・ Connection kit: 1 set
・ Protection bushing: 2
(*4)
To Next Page
