U s e r I n s t a l l a b l e F e a t u r e s
L i f e B o o k 7 0 0 S e r i e s f r o m F u j i t s u
107
5. Insert the connector of the external floppy
disk drive firmly into the port on your note-
book until it clicks.
To disconnect an external floppy disk drive:
1. Close all files and exit all applications
2. Turn off power to your notebook, close the
display and remove the AC adapter.
(See pages 24-25 for more information.)
3. Squeeze together firmly on the release but-
tons on either side of the external floppy disk
drive connector next to the body of your
notebook. (Figure 4-10.)
4. Pull the connector free.
5. Close the floppy disk drive port cover on
your notebook by tilting up and pressing
until it latches.
Figure 4-10 External Installation of a Floppy Disk Drive.
External Floppy Disk
Drive Port
External Floppy Disk
Drive Connector Cover
Connector Release Button
Connector
Release Button
External Floppy
Disk Drive
EXTERNAL INSTALLATION
OF A FLOPPY DISK DRIVE
To install a floppy disk drive externally,
you must purchase an optional external
floppy disk drive.
To connect a floppy disk drive externally:
1. Close all files and exit all applications.
2. Turn off power to your notebook, close
the display and remove the AC adapter.
(See pages 24-25 for more information.)
3. Open the external floppy disk drive port
cover on the right side panel of your note-
book, (see Figure 4-10),by gently pulling
on the left side of the cover and then
tilting it down.
4. Align the connector of the external floppy
disk drive with the connector towards the
body of your notebook with the wide side of
the connector up. (Figure 4-10)
