30
INTEGRATED ERGOTRAC
POINTING DEVICE
The ErgoTrac pointing device is composed of a
small joystick-like disc pointer control and two
buttons located in front of the keyboard. The
ErgoTrac pointing device has the function of a
mouse,and moves the cursor around on the
screen – up, down,left and right.A light pres-
sure with the tip of your finger is all that is
required to operate the ErgoTrac. The more
pressure you use the faster the cursor will move.
The second part of the ErgoTrac pointing
device – the buttons – function as mouse but-
tons,and the functions they perform depend
on the application you are running. Figure 2-6
shows the position of the ErgoTrac pointer
and buttons.
Figure 2-6 ErgoTrac Pointing Device
Right Button
Left Button
Cursor Control
Cursor
P O I N T
An external mouse can be connected to
the PS/2 port on the right side of the
notebook, and used simultaneously with
the ErgoTrac pointing device.
