S e c t i o n F o u r
114
d. Select the Display icon by double-
clicking on it.
e. Select the < s e t t i n g s > tab and change
the resolution to 800 x 600 pixels.
f. Change the monitor setting to Laptop
Display Panel (800 x 600).
g. Click on the < O K > button to activate the
new display settings. Your display should
now occupy the entire screen.
Future docking with Windows 95 can be done
in Suspend mode, Save-to-Disk mode or with
the power off and the system will automatically
detect whether you are docked,or not, when
you resume operation. Undocking should only
be done with power off or in PC Eject mode.
Figure 4-16 Port Replicator Front View
Port Replicator
Leveling
Alignment Foot
Alignment Notches
Docking Connector
Telephone Connector
Undock Request Button
Docked LED
Ready to
Undock LED
Docking Release Lever
Docking
Alignment Pins
