Model: ACUH18LUAS1 (3-way air outlet)
Measuring conditions
Fan speed Operation mode Ceiling mode
HIGH FAN STANDARD
Top view
Vertical airflow direction louver: Upward
(m)(ft)
00
3
7
10
13
1
2
3
4
(m)
(ft)
0
0
11
33 77 1010 1313
22 33 44
Unit: ft/s (m/s)
2 (0.5)1 (0.25)
3 (1.0) 7 (2.0)
1 (0.25)
1 (0.25)
2 (0.5)
2 (0.5)
3 (1.0)
3 (1.0)
7 (2.0)
7 (2.0)
Side view
Vertical airflow direction louver: Upward
(m)(ft)
00
3
7
10
1
2
3
(m)
(ft)
0
0
11
33 77 1010 1313
22 33 44
Unit: ft/s (m/s)
7 (2.0)
3 (1.0)
3 (1.0)
2 (0.5)2 (0.5)
1 (0.25)1 (0.25)
Side view
Vertical airflow direction louver: Downward
(m)(ft)
00
3
7
10
1
2
3
(m)
(ft)
0
0
11
33 77 1010 1313
22 33 44
Unit: ft/s (m/s)
7 (2.0)
1 (0.25)
7 (2.0)
3 (1.0)
3 (1.0)
2 (0.5)
2 (0.5)
1 (0.25)
- 16 -
5-1. Air velocity distributions 5. Fan performance
CASSETTE TYPE ADUH09-18LUAS1 CASSETTE TYPE ADUH09-18LUAS1
