Fujitsu ACUH09LUAS1 Design & Technical Manual

1. Specifications
Type
Cassette
Inverter heat pump
Model name ACUH09LUAS1 ACUH12LUAS1 ACUH18LUAS1
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—253 V
Capacity
Cooling Cooling
Rated
kW 2.64 3.52 5.02
Btu/h 9,000 12,000 17,100
Min.—Max.
kW 0.90—3.20 0.90—4.00 0.90—5.90
Btu/h 3,100—11,000 3,100—13,600 3,100—20,100
Heating
47 °FDB
(Outdoor temp.)
Rated
kW 3.52 4.69 6.33
Btu/h 12,000 16,000 21,600
Min.—Max.
kW 0.90—4.70 0.90—5.70 0.90—7.00
Btu/h 3,100—16,000 3,100—19,400 3,100—23,900
17 °FDB
(Outdoor temp.)
Rated
kW 2.17 3.08 4.22
Btu/h 7,400 10,500 14,400
Max.
kW 3.08 4.98 5.75
Btu/h 10,500 17,000 19,600
Input power
Cooling Cooling
Rated
kW
0.66 0.94 1.37
Max. 1.05 2.06 2.35
Heating
47 °FDB
(Outdoor temp.)
Rated 0.93 1.44 1.81
Max. 1.72 1.79 2.57
17 °FDB
(Outdoor temp.)
Rated 0.78 1.07 1.49
Max. 1.42 2.01 2.56
Current
Cooling
Rated A
3.3 4.2 6.1
Heating 4.6 6.4 8.1
EER Cooling
kW/kW 4.00 3.74 3.66
Btu/hW 13.6 12.8 12.5
COP Heating
kW/kW 3.78 3.25 3.50
Btu/hW 12.9 11.1 11.9
SEER Cooling Btu/hW 22.5 22.1 20.8
HSPF Heating Btu/hW 12.5 12.2 11.6
Power factor
Cooling
%
87.0 97.3 97.6
Heating 86.0 97.8 97.2
Moisture removal pints/h (L/h) 1.3 (0.6) 2.5 (1.2) 4.6 (2.2)
Maximum operating current *
1
Cooling
A
6.8 9.8 11.8
Heating 9.3 11.3 14.8
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
318 (540) 359 (610) 435 (740)
MED 288 (490) 312 (530) 341 (580)
LOW 259 (440) 276 (470) 288(490)
QUIET 230 (390) 241 (410)
Heating
HIGH 318 (540) 359 (610) 435 (740)
MED 288 (490) 312 (530) 341 (580)
LOW 259 (440) 276 (470) 288 (490)
QUIET 230 (390) 241 (410)
Type × Q'ty Turbo × 1
Motor output W 54
Sound pressure level *
2
Cooling
HIGH
dB (A)
33 37 42
MED 32 33 36
LOW 29 31 32
QUIET 28
Heating
HIGH 34 37 44
MED 32 33 40
LOW 29 31 36
QUIET 27 28 30
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main 1: 8-4/16 × 51-9/16 × 1/2
(210 × 1,310 × 13.3)
Main 2: 8-4/16 × 49-3/16 × 1/2
(210 × 1,250 × 13.3)
Fin pitch FPI
Main 1: 1.2
Main 2: 1.2
Rows × Stages
Main 1: 1 × 10
Main 2: 1 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
in (mm)
9-5/8 × 22-7/16 × 22-7/16 (245 × 570 × 570)
Gross 10-7/16 × 28-3/4 × 24-5/8 (265 × 730 × 625)
Weight
Net
lb (kg)
33 (15)
Gross 40 (18) 42 (19)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.70)
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Drain hose
Material HARD PVC
Size in (mm)
Ø3/4 (Ø20.7) [I.D.]
Ø1-1/16 (Ø26.6) [O.D.]
Cassette grille
(Grid type: Option)
Model name
UTG-CCGFGA
Material PS
Color
White
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × W × D)
Net
in (mm)
1-15/16 × 24-7/16 × 24-7/16 (49 × 620 × 620)
Gross 4-3/4 × 30-1/8 × 29-3/4 (120 × 765 × 755)
Weight
Net
lb (kg)
5.1 (2.3)
Gross 10 (4.5)
- 2 -
1. Specifications
CASSETTE TYPE ADUH09-18LUAS1 CASSETTE TYPE ADUH09-18LUAS1
