Fujitsu ACUH09LUAS1 Design & Technical Manual

6-3. Model: AOUH18LUAS1
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length
m
5 7.5 10 15 20 25 30
ft 16 25 33 49 66 82 98
Height difference H
Indoor unit is
higher than
outdoor unit
*1
15 49 - - - 0.951 0.950 0.947 0.941
10 33 - - 0.979 0.967 0.966 0.962 0.956
7.5 25 - 0.988 0.983 0.971 0.970 0.966 0.960
5 16 0.994 0.992 0.987 0.975 0.974 0.970 0.964
0 0 1.002 1.000 0.995 0.983 0.982 0.978 0.972
Indoor unit is
lower than
outdoor unit
*2
-5 -16 1.002 1.000 0.995 0.983 0.982 0.978 0.972
-7.5 -25 - 1.000 0.995 0.983 0.982 0.978 0.972
-10 -33 - - 0.995 0.983 0.982 0.978 0.972
-15 -49 - - - 0.983 0.982 0.978 0.972
HEATING
Pipe length
m
5 7.5 10 15 20 25 30
ft 16 25 33 49 66 82 98
Height difference H
Indoor unit is
higher than
outdoor unit
*1
15 49 - - - 0.994 0.979 0.949 0.919
10 33 - - 1.012 0.994 0.979 0.949 0.919
7.5 25 - 1.000 1.012 0.994 0.979 0.949 0.919
5 16 0.969 1.000 1.012 0.994 0.979 0.949 0.919
0 0 0.969 1.000 1.012 0.994 0.979 0.949 0.919
Indoor unit is
lower than
outdoor unit
*2
-5 -16 0.964 0.995 1.007 0.989 0.974 0.944 0.915
-7.5 -25 - 0.993 1.004 0.986 0.972 0.942 0.911
-10 -33 - - 1.002 0.984 0.969 0.940 0.909
-15 -49 - - - 0.974 0.959 0.930 0.899
- 84 -
6-3. Model: AOUH18LUAS1 6. Capacity compensation rate for pipe length and height difference
