Fujitsu AOU36RLXFZH Design & Technical Manual

- 235 -
OUTDOOR UNIT AOU36RLXFZH
Be sure to disconnect the power supply or turn off the breaker before changing the DIP switch
setting.
Switch Function or operation method Factory setting
SW1 Push
• For the test run start and stop.
• For the pump down start and stop.
—
SW2 Push
• For when check run function is activated.
• For displaying the check run.
• For resetting the Automatic wiring correction
memory.
—
SET1-1 DIP For selecting cooling or heating during test operation.OFF
SET1-2 DIP For switching SW1 operation. OFF
SET1-3 DIP
For switching the base heater.
(For extra cold climate area model only)
ON
SET1-4 DIP (Prohibited)
OFF
(Do not change)
SET2-1 DIP
• For selecting outdoor unit low noise operation func-
tion.
• To use this function, the Central remote controller
(option) is necessary.
OFF
SET2-2 DIP (Prohibited)
OFF
(Do not change)
SET2-3 DIP (Prohibited)
OFF
(Do not change)
SET2-4 DIP (Prohibited)
OFF
(Do not change)
SET3-1 DIP (Prohibited)
OFF
(Do not change)
SET3-2 DIP (Prohibited)
OFF
(Do not change)
SET3-3 DIP (Prohibited)
OFF
(Do not change)
SET3-4 DIP (Prohibited)
OFF
(Do not change)
