Fujitsu AOU9RLS3 User Manual

- (01 - 09) -
WALL MOUNTED TYPE ASU9-15RLS3 WALL MOUNTED TYPE ASU9-15RLS3
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

: ASU9RLS3
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
SHC : Sensible Heat Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
AFR 489
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15 8.33 8.06 0.19 9.29 8.11 0.19 10.25 8.87 0.20 10.57 9.53 0.20 11.17 9.50 0.20 11.81 10.07 0.21
23 8.16 7.88 0.22 9.09 7.91 0.22 10.03 8.65 0.23 10.35 9.31 0.22 10.94 9.28 0.22 11.56 9.91 0.23
32 7.99 7.69 0.22 8.90 7.75 0.23 9.81 8.45 0.24 10.13 9.16 0.23 10.70 9.09 0.23 11.32 9.68 0.24
41 7.81 7.58 0.24 8.71 7.61 0.24 9.60 8.28 0.25 9.90 8.97 0.24 10.47 8.90 0.24 11.07 9.50 0.25
50 7.64 7.36 0.22 8.51 7.41 0.22 9.38 8.07 0.24 9.68 8.76 0.23 10.24 8.70 0.23 10.83 9.26 0.24
59 7.47 7.24 0.27 8.32 7.27 0.27 9.16 7.91 0.28 9.46 8.57 0.28 10.01 8.51 0.28 10.58 9.08 0.28
67 8.42 8.15 0.34 9.38 8.18 0.35 10.33 8.94 0.36 10.67 9.63 0.36 11.28 9.59 0.36 11.93 10.18 0.37
77 8.01 7.74 0.39 8.93 7.77 0.39 9.85 8.49 0.40 10.16 9.15 0.40 10.74 9.11 0.41 11.35 9.73 0.41
87 7.57 7.29 0.44 8.45 7.36 0.44 9.31 8.01 0.45 9.58 8.67 0.45 10.16 8.63 0.46 10.74 9.18 0.46
95 7.09 6.88 0.48 7.91 6.91 0.49 8.73 7.53 0.50 9.00 8.15 0.50 9.55 8.12 0.51 10.06 8.63 0.51
104 6.00 5.67 0.45 6.68 6.16 0.46 7.36 6.71 0.46 7.60 7.26 0.46 8.05 7.22 0.47 8.52 7.70 0.47
115 5.52 5.33 0.45 6.17 5.71 0.46 6.78 6.22 0.46 6.99 6.74 0.46 7.43 6.71 0.47 7.84 7.15 0.47
AFR 13.8
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 2.44 2.36 0.19 2.72 2.38 0.19 3.00 2.60 0.20 3.10 2.79 0.20 3.27 2.78 0.20 3.46 2.95 0.21
-5.0 2.39 2.31 0.22 2.67 2.32 0.22 2.94 2.53 0.23 3.03 2.73 0.22 3.21 2.72 0.22 3.39 2.90 0.23
0.0 2.34 2.25 0.22 2.61 2.27 0.23 2.88 2.48 0.24 2.97 2.68 0.23 3.14 2.67 0.23 3.32 2.84 0.24
5.0 2.29 2.22 0.24 2.55 2.23 0.24 2.81 2.43 0.25 2.90 2.63 0.24 3.07 2.61 0.24 3.25 2.79 0.25
10.0 2.24 2.16 0.22 2.49 2.17 0.22 2.75 2.37 0.24 2.84 2.57 0.23 3.00 2.55 0.23 3.17 2.71 0.24
15.0 2.19 2.12 0.27 2.44 2.13 0.27 2.69 2.32 0.28 2.77 2.51 0.28 2.93 2.49 0.28 3.10 2.66 0.28
19.4 2.47 2.39 0.34 2.75 2.40 0.35 3.03 2.62 0.36 3.13 2.82 0.36 3.31 2.81 0.36 3.50 2.98 0.37
25.0 2.35 2.27 0.39 2.62 2.28 0.39 2.89 2.49 0.40 2.98 2.68 0.40 3.15 2.67 0.41 3.33 2.85 0.41
30.6 2.22 2.14 0.44 2.48 2.16 0.44 2.73 2.35 0.45 2.81 2.54 0.45 2.98 2.53 0.46 3.15 2.69 0.46
35.0 2.08 2.02 0.48 2.32 2.03 0.49 2.56 2.21 0.50 2.64 2.39 0.50 2.80 2.38 0.51 2.95 2.53 0.51
40.0 1.76 1.66 0.45 1.96 1.80 0.46 2.16 1.97 0.46 2.23 2.13 0.46 2.36 2.12 0.47 2.50 2.26 0.47
46.0 1.62 1.56 0.45 1.81 1.67 0.46 1.99 1.82 0.46 2.05 1.98 0.46 2.18 1.97 0.47 2.30 2.10 0.47
