Fujitsu AOU9RLS3 User Manual

- (01 - 05) -
WALL MOUNTED TYPE ASU9-15RLS3 WALL MOUNTED TYPE ASU9-15RLS3
SPECIFICATIONS3.
NOTE :
• Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67°C) DB / 67°F (19.44°C) WB, and outdoor temperature of 95°F (35°C) DB / 75°F (23.9°C) WB.
Heating : Indoor temperature of 70°F (21.11°C) DB / 59°F (15°C) WB, and outdoor temperature of 47°F (8.33°C) DB / 43°F (6.11°C) WB.
Pipe length : 24ft.7in (7.5m), Height difference:0 m. (Outdoor unit-Indoor unit)
• The protective function might work when using it outside the operation range.
*1: The maximum current is the maximum value when operated within the operation range.
*2: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specied values here.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASU9RLS3 ASU12RLS3 ASU15RLS3
Power source 208 / 230V ~ 60Hz
Available voltage range 188 - 253V
Capacity
Cooling
Rated
kW 2.64 3.52 4.25
Btu/h 9,000 12,000 14,500
Min - Max
kW 0.90 - 3.60 0.90 - 4.00 0.90 - 5.40
Btu/h 3,100 - 12,000 3,100 - 13,600 3,100 - 18,400
Heating
Rated
kW 3.52 4.69 5.28
Btu/h 12,000 16,000 18,000
Min - Max
kW 0.90 - 6.45 0.90 - 6.48 0.90 - 7.00
Btu/h 3,100 - 22,000 3,100 - 22,100 31,00 - 23,900
Input power
Cooling
Rated
kW
0.50 0.79 1.04
Max 0.85 0.99 1.56
Heating
Rated 0.66 1.01 1.15
Max 1.93 1.94 2.19
Current
Cooling
Rated A
2.5 3.8 4.8
Heating 3.3 4.7 5.2
EER Cooling
kW/kW 5.28 4.46 4.09
Btu/hW 18.0 15.2 13.9
COP Heating
kW/kW 5.33 4.64 4.59
Btu/hW 18.2 15.8 15.7
SEER Cooling Btu/hW 33.0 29.3 25.3
HSPF Heating Btu/hW 14.2 14.0 13.4
POWER FACTOR
Cooling
%
87 90 94
Heating 87 93 96
Moisture removal pints/h (l/h) 2.6 (1.2) 2.7 (1.3) 4.0 (1.9)
Maximum operating current *1
Cooling
A
9.4 9.4 9.9
Heating 10.9 10.9 13.9
Fan
Airow rate
Cooling
High
CFM
(m
3
/h)
489(830) 547(930)
Med 400(680) 459(780)
Low 341(580) 371(630)
Quiet 224(380) 259(440)
Heating
High 489(830) 547(930)
Med 400(680) 459(780)
Low 341(580) 371(630)
Quiet 224(380) 294(500)
Type × Q'ty Cross ow fan × 1
Motor output W 61
Sound pressure level *2
Cooling
High
dB (A)
42 45
Med 37 40
Low 32 34
Quiet 23 26
Heating
High 41 45
Med 35 39
Low 31 33
Quiet 23 27
Heat exchanger type
Dimensions
(H × W × D)
in. (mm)
Main : 15-1/8 × 28-3/8 × 1-3/16 (384 × 720 × 30)
Sub : 3-5/16 × 28-3/8 × 1/2 (84 × 720 × 13.3)
4-15/16 × 28-3/8 × 1/2 (126 × 720 × 13.3)
Fin pitch FPI Main : 21 Sub : 18
Rows × Stages Main : 3 × 24 Sub : 1 × 10
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of MUNSELL 5PB 9.25/0.5
Dimensions
(H × W × D)
Net
inch 11 - 5/8 × 37 × 10 - 5/8
mm 295 × 940 × 270
Gross
inch 14 - 3/8 × 40 - 15/16 × 14
mm 365 × 1040 × 355
Weight
Net
lbs. (kg)
31 (14.0)
Gross 37 (17.0)
Connection pipe
Size
Liquid
in. (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.7)
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 88 (16 to 30)
Remote controller type Wireless
Drain hose
Material PP+LLDPF
Size in.(mm)
Ø9/16 (Ø13.8) (I.D.)
Ø5/8 to Ø11/16 (Ø15.8 to Ø16.7) (O.D.)
