Fujitsu AOU9RLS3 User Manual

- (02 - 03) -
OUTDOOR UNIT AOU9-15RLS3 OUTDOOR UNIT AOU9-15RLS3
REFRIGERANT CIRCUIT3.
MODEL

: AOU9RLS3, AOU12RLS3
2-Way
valve
Strainer
Strainer
3-Way
valve
MufflerMuffler
Acccumlator
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
Compressor
Cooling
Heating
Refrigerant pipe diameter
Liquid: 1/4" (6.35 mm)
Gas: 3/8" (9.52 mm)
Th
D
Th
R
Th
PI
Th
HO
Th
O
Th
R
Th
PI
Th
D
Th
O
Th
HO
Thermistor (Room Temp.)
Thermistor (Pipe Temp.)
Thermistor (Discharge Temp.)
Thermistor (Outdoor Temp.)
Thermistor (Heat Exchanger Out Temp.)

Fujitsu AOU9RLS3 Specifications

General

Brand	Fujitsu
Model	AOU9RLS3
Category	Air Conditioner
Language	English
