Fujitsu AOU9RLS3 User Manual

- (02 - 02) -
OUTDOOR UNIT AOU9-15RLS3 OUTDOOR UNIT AOU9-15RLS3
DIMENSIONS2.
MODEL

: AOU9RLS3, AOU12RLS3, AOU15RLS3
Unit : in. (mm)
Bottom view
Air flow
4-5/16
(110)
12-5/8 (320)
21-1/4 (540)
8-1/4 (209)
4-Ø7/16 (11.3) hole
6-7/8 (175)
Drain pipe
mounting place
(Ø13/16 (20))
31-1/8(790)
24-7/16(620)
13/16(20)
3/8(9)
3/4(19) 2-5/8(67)
11-5/16(288)
11/16(18) 7/8(23)
13-7/8(352)
24 (600) or more
4 (100) or more
8 (200) or more
4 (100)
or more
10 (250) or more
(Service space)
CAUTION
:KHQWKHRXWGRRUWHPSHUDWXUHLV&RUOHVVGRQRWXVH
WKHDFFHVVRU\GUDLQSLSHDQGGUDLQFDS,IWKHGUDLQSLSH
DQGGUDLQFDSDUHXVHGWKHGUDLQZDWHULQWKHSLSHPD\
IUHH]HLQH[WUHPHO\FROGZHDWKHU5HYHUVHF\FOHPRGHO
RQO\
,QDUHDVZLWKKHDY\VQRZIDOOLIWKHLQWDNHDQGRXWOHWRI
RXWGRRUXQLWLVEORFNHGZLWK VQRZLWPLJKWEHFRPH
GLIILFXOWWRJHWZDUPDQGLWLVOLNHO\WRFDXVHEUHDNGRZQ
3OHDVHFRQVWUXFWDFDQRS\DQGDSHGHVWDORUSODFHWKH
XQLWRQDKLJKVWDQGORFDOFRQILJXUHG
INSTALLATION PLACE

•Height above the oor level should be 50 mm or more.
•To obtain better operation efciency, when the outdoor unit is installed, be sure to open the front
and left side.
