Fujitsu AOU9RLS3 User Manual

- (02 - 01) -
OUTDOOR UNIT AOU9-15RLS3 OUTDOOR UNIT AOU9-15RLS3
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AOU9RLS3 AOU12RLS3 AOU15RLS3
Power sourse 208 / 230V
~
60Hz
Available voltage range 188 - 253V
Starting current A 3.3 4.7 5.2
Fan
Airow
rate
Cooling
CFM
(m
3
/h)
989 (1,680) 1,206 (2,050)
Heating 1,082 (1,840)
Type × Q'ty Propeller fan × 1
Motor output W 49
Sound pressure level
Cooling
dB (A)
42 43 49
Heating 47 50
Heat exchanger type
Dimensions
(H × W × D)
in. 23-1/8 × 34-11/16 × 1-7/16
mm 588 × 881 × 36.4
Fin pitch FPI 20
Rows × Stages 2 × 28
Pipe type Copper
Fin Type Aluminum
Compressor
Type × Q'ty Rotary × 1
Motor output W 850 1,000
Refrigerant
Type R410A
Charge
lbs.oz. 2lbs.14oz. 3lbs.1oz.
kg 1.30 1.40
Refrigerant oil Type FREOL α68SZ
Enclosure
Material Steel
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
in. 24 - 1/2 × 31 - 1/8 × 11 - 7/16
mm 620 × 790 × 290
Gross
in. 28 - 1/16 × 37-3/16 × 15 - 9/16
mm 713 × 945 × 395
Weight
Net
lbs.(kg)
84 (38) 86 (39)
Gross 93 (42)
Connenction pipe
Size
Liquid
in. (mm)
Ø 1/4 (Ø 6.35)
Gas Ø 3/8 (Ø 9.52) Ø 1/2 (Ø 12.7)
Method Flare
Pre - charge length
ft. (m)
49 (15)
Max. length 66 (20)
Max. height difference 49 (15)
Operation range
Cooling
°F (°C)
14 to 115 (-10 to 46)
Heating -5 to 75 (-21 to 24)
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67°C) DB / 67°F (19.44°C) WB, and outdoor temperature of 95°F (35°C) DB / 75°F (23.9°C) WB.
Heating : Indoor temperature of 70°F (21.11°C) DB / 59°F (15°C) WB, and outdoor temperature of 47°F (8.33°C) DB / 43°F (6.11°C) WB.
Pipe length : 24ft.7in (7.5m), Height difference:0 m. (Outdoor unit - Indoor unit)
The protective function might work when using it outside the operation range.
