Fujitsu AOYG09KHCAN - 1-2. Outdoor units

¢
Installation space requirement
Provide sufficient installation space for product safety.
Outline of unit
Unit: mm
50 or more
127 or more
50 or more
133 or more
1,500 or more
50 or more
84 or more
1,800 or more
- 6 -
2-1. Models: ASYG09KHCA, ASYG12KHCA, and ASYG14KHCA 2. Dimensions
