¢ Casing assy
259
256
253
254
252
258
250
251
257
255
Item no. Part no. Part name Service part
250 9318840025 Casing ♦
251 9382222000 Casing cover F ♦
252 9318862003 Casing cover B ♦
253 9318830002 Casing cover L ♦
254 9318831009 Casing cover R ♦
255 9319229027 L and R louver assy ♦
256 9320458003 Fan guard ♦
257 9318743029 Pipe bracket ♦
258 9316177017 Drain cap ♦
259 9316904019 Drain hose assy ♦
2-1. Models: ASYG09KHCA, ASYG12KHCA, and ASYG14KHCA - (02-7) - 2. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
