Fujitsu AOYG09KHCAN User Manual

1. Specifications
1-1. Indoor units
Type
Wall mounted
Inverter heat pump
Model name ASYG09KHCA ASYG12KHCA ASYG14KHCA
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Energy rank Cooling 1
Capacity
Cooling
Rated
kW 2.50 3.50 4.20
Btu/h 8,500 11,900 14,300
Min.—Max.
kW 0.90—4.65 0.90—4.80 0.90—5.50
Btu/h 3,100—15,800 3,100—16,300 3,100—18,700
Heating
Rated
kW 3.20 4.00 5.40
Btu/h 10,900 13,600 18,400
Min.—Max.
kW 0.90—7.20 0.90—7.40 0.9—8.20
Btu/h 3,100—24,500 3,100—25,200 3,100—27,900
Input power
Cooling
Rated
kW
0.45 0.76 0.98
Max. 1.26 1.50 1.53
Heating
Rated 0.58 0.79 1.16
Max. 2.20 2.25 2.35
Fan
HIGH
W
23.0 23.0 32.0
MED 13.0 13.0 20.0
LOW 9.0 9.0 12.0
QUIET 5.0 5.0 6.0
Current
Cooling
Rated A
2.1 3.5 4.4
Heating 2.7 3.6 5.2
EER Cooling kW/kW 5.56 4.61 4.29
COP Heating kW/kW 5.52 5.06 4.66
Sensible capacity Cooling kW 2.10 2.94 3.59
Power factor
Cooling % 93.2 94.4 96.8
Heating % 93.4 95.4 97.0
Moisture removal L/h (pints/h) 1.0 (1.8) 1.1 (1.9) 1.7 (3.0)
Maximum operating current *1
Cooling
A
6.5 7.5 9.0
Heating 10.5 11.0 11.5
Fan
Airflow rate
Cooling
HIGH
m
3
/h
830 900
MED 680 780
LOW 580 630
QUIET 380 440
Heating
HIGH 830 900
MED 680 780
LOW 580 630
QUIET 380 500
Type × Q'ty Cross flow fan × 1
Motor output W 61
Sound pressure level *2
Cooling
HIGH
dB (A)
42 45
MED 37 40
LOW 33 35
QUIET 23 26
Heating
HIGH 41 44
MED 35 39
LOW 31 33
QUIET 23 27
Heat exchanger type
Dimensions (H × W × D)
mm
Main1: 384 × 720 × 30
Sub1: 84 × 720 × 13.3
Sub2: 126 × 720 × 13.3
Fin pitch
Main1: 1.2
Sub1: 1.4
Sub2: 1.4
Rows × Stages
Main1: 3 × 24
Sub1: 1 × 4
Sub2: 1 × 6
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of MUNSELL 5PB 9.25/0.5
Dimensions
(H × W × D)
Net
mm
295 × 940 × 270
Gross 355 × 1,040 × 365
Weight
Net
kg
14
Gross 17
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Drain hose
Material PP+HDPE
Size mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair™)
