Fujitsu AOYG36LBLA5 User Manual

4. Press the MODE button again to return to the clock display. The custom code will be
changed.
• If no buttons are pressed within 30 seconds after the custom code is displayed, the system re-
turns to the original clock display. In this case, start again from step 1.
• The air conditioner custom code is set to A prior to shipment.
• The remote controller resets to custom code A when the batteries in the remote controller are
replaced. If you use a custom code other than custom code A, reset the custom code after re-
placing the batteries. If you do not know the air conditioner custom code setting, try each of the
custom codes (
→ → → ) until you find the code which operates the air conditioner.
- 207 -
MULTI TYPE 5, 6 ROOMS TYPE

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
