Fujitsu AOYG36LBLA5 User Manual

Remote sensor unit
Model: UTY-XSZX
Auto louver grille kit
Models: UTD-GXTA-W
*1
, UTD-GXTB-W
*2
For slim duct type and mini duct type
*1: For slim duct type and mini duct type (07-14
models)
*2: For slim duct type and mini duct type (18 models)
Communication kit
Model: UTY-XCBXZ2
Communication kit
Model: UTY-TWBXF
For wall mounted (LM) type
For wall mounted (LU) type
Half concealed kit
Model: UTR-STA
Wireless LAN interface
Model: UTY-TFNXZ1
*1
, UTY-TFSXZ1
*2
For floor type
*1: For compact cassette type, slim duct type, wall
mounted type, floor/ceiling type, and floor type
*2: For mini duct type
- 269 -
MULTI TYPE 5, 6 ROOMS TYPE

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
