Heating
Combination of indoor unit Rated capacity for each indoor unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
COP
(W/W)Room
Total
Room
Min.
Rated
Max. Min.
Rated
Max.
1 2 3 4 5 6 1 2 3 4 5 6
12 24 — — — — 36 4.07 8.13 — — — — 3.5 12.2 13.1 0.7 3.41 3.54 3.58
14 24 — — — — 38 4.61 7.89 — — — — 3.5 12.5 13.8 0.7 3.56 3.76 3.51
18 18 — — — — 36 6.10 6.10 — — — — 3.5 12.2 13.1 0.7 3.41 3.54 3.58
18 24 — — — — 42 5.66 7.54 — — — — 3.5 13.2 15.3 0.7 3.78 4.20 3.49
24 24 — — — — 48 6.75 6.75 — — — — 3.5 13.5 16.0 0.7 3.89 4.41 3.47
7 7 24 — — — 38 2.30 2.30 7.90 — — — 3.5 12.5 13.8 0.7 3.43 3.76 3.64
7 9 18 — — — 34 2.35 3.02 6.03 — — — 3.5 11.4 12.4 0.7 2.98 3.33 3.83
7 9 24 — — — 40 2.24 2.88 7.68 — — — 3.5 12.8 14.5 0.7 3.54 3.98 3.62
7 12 18 — — — 37 2.33 3.99 5.98 — — — 3.5 12.3 13.5 0.7 3.35 3.65 3.67
7 12 24 — — — 43 2.17 3.71 7.42 — — — 3.5 13.3 15.6 0.7 3.69 4.30 3.60
7 14 14 — — — 35 2.40 4.80 4.80 — — — 3.5 12.0 12.7 0.7 3.15 3.44 3.81
7 14 18 — — — 39 2.28 4.56 5.86 — — — 3.5 12.7 14.2 0.7 3.49 3.87 3.64
7 14 24 — — — 45 2.10 4.20 7.20 — — — 3.5 13.5 16.0 0.7 3.75 4.41 3.60
7 18 18 — — — 43 2.16 5.57 5.57 — — — 3.5 13.3 15.6 0.7 3.69 4.30 3.60
7 18 24 — — — 49 1.93 4.96 6.61 — — — 3.5 13.5 16.0 0.7 3.74 4.41 3.61
7 24 24 — — — 55 1.72 5.89 5.89 — — — 3.5 13.5 16.0 0.7 3.72 4.41 3.63
9 9 18 — — — 36 3.05 3.05 6.10 — — — 3.5 12.2 13.1 0.7 3.28 3.54 3.72
9 9 24 — — — 42 2.83 2.83 7.54 — — — 3.5 13.2 15.3 0.7 3.64 4.20 3.63
9 12 14 — — — 35 3.09 4.11 4.80 — — — 3.5 12.0 12.7 0.7 3.15 3.44 3.81
9 12 18 — — — 39 2.93 3.91 5.86 — — — 3.5 12.7 14.2 0.7 3.49 3.87 3.64
9 12 24 — — — 45 2.70 3.60 7.20 — — — 3.5 13.5 16.0 0.7 3.75 4.41 3.60
9 14 14 — — — 37 3.00 4.65 4.65 — — — 3.5 12.3 13.5 0.7 3.35 3.65 3.67
9 14 18 — — — 41 2.85 4.44 5.71 — — — 3.5 13.0 14.9 0.7 3.59 4.09 3.62
9 14 24 — — — 47 2.59 4.02 6.89 — — — 3.5 13.5 16.0 0.7 3.74 4.41 3.61
9 18 18 — — — 45 2.70 5.40 5.40 — — — 3.5 13.5 16.0 0.7 3.75 4.41 3.60
9 18 24 — — — 51 2.38 4.76 6.36 — — — 3.5 13.5 16.0 0.7 3.73 4.41 3.62
9 24 24 — — — 57 2.14 5.68 5.68 — — — 3.5 13.5 16.0 0.7 3.71 4.41 3.64
12 12 12 — — — 36 4.07 4.07 4.07 — — — 3.5 12.2 13.1 0.7 3.28 3.54 3.72
12 12 14 — — — 38 3.94 3.95 4.61 — — — 3.5 12.5 13.8 0.7 3.43 3.76 3.64
12 12 18 — — — 42 3.77 3.77 5.66 — — — 3.5 13.2 15.3 0.7 3.64 4.20 3.63
12 12 24 — — — 48 3.38 3.38 6.74 — — — 3.5 13.5 16.0 0.7 3.74 4.41 3.61
12 14 14 — — — 40 3.84 4.48 4.48 — — — 3.5 12.8 14.5 0.7 3.54 3.98 3.62
12 14 18 — — — 44 3.68 4.30 5.52 — — — 3.5 13.5 16.0 0.7 3.75 4.41 3.60
12 14 24 — — — 50 3.24 3.78 6.48 — — — 3.5 13.5 16.0 0.7 3.74 4.41 3.61
12 18 18 — — — 48 3.38 5.06 5.06 — — — 3.5 13.5 16.0 0.7 3.74 4.41 3.61
12 18 24 — — — 54 3.00 4.50 6.00 — — — 3.5 13.5 16.0 0.7 3.72 4.41 3.63
12 24 24 — — — 60 2.70 5.40 5.40 — — — 3.5 13.5 16.0 0.7 3.71 4.41 3.64
14 14 14 — — — 42 4.40 4.40 4.40 — — — 3.5 13.2 15.3 0.7 3.64 4.20 3.63
14 14 18 — — — 46 4.11 4.11 5.28 — — — 3.5 13.5 16.0 0.7 3.75 4.41 3.60
14 14 24 — — — 52 3.63 3.63 6.24 — — — 3.5 13.5 16.0 0.7 3.73 4.41 3.62
14 18 18 — — — 50 3.78 4.86 4.86 — — — 3.5 13.5 16.0 0.7 3.74 4.41 3.61
14 18 24 — — — 56 3.38 4.34 5.78 — — — 3.5 13.5 16.0 0.7 3.72 4.41 3.63
14 24 24 — — — 62 3.04 5.23 5.23 — — — 3.5 13.5 16.0 0.7 3.70 4.41 3.65
18 18 18 — — — 54 4.50 4.50 4.50 — — — 3.5 13.5 16.0 0.7 3.72 4.41 3.63
18 18 24 — — — 60 4.05 4.05 5.40 — — — 3.5 13.5 16.0 0.7 3.71 4.41 3.64
7 7 7 14 — — 35 2.40 2.40 2.40 4.80 — — 3.5 12.0 12.7 0.7 2.98 3.44 4.03
7 7 7 18 — — 39 2.28 2.28 2.28 5.86 — — 3.5 12.7 14.2 0.7 3.35 3.87 3.79
7 7 7 24 — — 45 2.10 2.10 2.10 7.20 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
7 7 9 12 — — 35 2.40 2.40 3.09 4.11 — — 3.5 12.0 12.7 0.7 2.98 3.44 4.03
7 7 9 14 — — 37 2.33 2.33 2.99 4.65 — — 3.5 12.3 13.5 0.7 3.19 3.65 3.86
7 7 9 18 — — 41 2.22 2.22 2.85 5.71 — — 3.5 13.0 14.9 0.7 3.46 4.09 3.76
7 7 9 24 — — 47 2.01 2.01 2.59 6.89 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 7 12 12 — — 38 2.30 2.30 3.95 3.95 — — 3.5 12.5 13.8 0.7 3.28 3.76 3.81
7 7 12 14 — — 40 2.24 2.24 3.84 4.48 — — 3.5 12.8 14.5 0.7 3.41 3.98 3.75
7 7 12 18 — — 44 2.15 2.15 3.68 5.52 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
7 7 12 24 — — 50 1.89 1.89 3.24 6.48 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 7 14 14 — — 42 2.20 2.20 4.40 4.40 — — 3.5 13.2 15.3 0.7 3.52 4.20 3.75
7 7 14 18 — — 46 2.05 2.05 4.11 5.29 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
7 7 14 24 — — 52 1.82 1.82 3.63 6.23 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
7 7 18 18 — — 50 1.89 1.89 4.86 4.86 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 7 18 24 — — 56 1.69 1.69 4.34 5.78 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
7 7 24 24 — — 62 1.52 1.52 5.23 5.23 — — 3.5 13.5 16.0 0.7 3.56 4.41 3.79
7 9 9 9 — — 34 2.34 3.02 3.02 3.02 — — 3.5 11.4 12.4 0.7 2.82 3.33 4.04
7 9 9 12 — — 37 2.33 2.99 2.99 3.99 — — 3.5 12.3 13.5 0.7 3.19 3.65 3.86
7 9 9 14 — — 39 2.28 2.93 2.93 4.56 — — 3.5 12.7 14.2 0.7 3.35 3.87 3.79
7 9 9 18 — — 43 2.17 2.78 2.78 5.57 — — 3.5 13.3 15.6 0.7 3.56 4.30 3.74
7 9 9 24 — — 49 1.93 2.48 2.48 6.61 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 9 12 12 — — 40 2.24 2.88 3.84 3.84 — — 3.5 12.8 14.5 0.7 3.41 3.98 3.75
7 9 12 14 — — 42 2.20 2.83 3.77 4.40 — — 3.5 13.2 15.3 0.7 3.52 4.20 3.75
7 9 12 18 — — 46 2.05 2.64 3.52 5.29 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
7 9 12 24 — — 52 1.82 2.34 3.12 6.22 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
7 9 14 14 — — 44 2.15 2.75 4.30 4.30 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
7 9 14 18 — — 48 1.97 2.53 3.94 5.06 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 9 14 24 — — 54 1.75 2.25 3.50 6.00 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
7 9 18 18 — — 52 1.82 2.34 4.67 4.67 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
7 9 18 24 — — 58 1.63 2.09 4.19 5.59 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
7 12 12 12 — — 43 2.17 3.71 3.71 3.71 — — 3.5 13.3 15.6 0.7 3.56 4.30 3.74
7 12 12 14 — — 45 2.10 3.60 3.60 4.20 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
7 12 12 18 — — 49 1.93 3.31 3.31 4.95 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 12 12 24 — — 55 1.72 2.95 2.95 5.88 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
7 12 14 14 — — 47 2.01 3.45 4.02 4.02 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
7 12 14 18 — — 51 1.85 3.18 3.71 4.76 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
7 12 14 24 — — 57 1.66 2.84 3.32 5.68 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
7 12 18 18 — — 55 1.72 2.94 4.42 4.42 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
7 12 18 24 — — 61 1.55 2.66 3.98 5.31 — — 3.5 13.5 16.0 0.7 3.56 4.41 3.79
7 14 14 14 — — 49 1.92 3.86 3.86 3.86 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
- 357 -
OUTDOOR UNIT AOYG45LBLA6

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
