Fujitsu AOYG36LBLA5 User Manual

Combination of indoor unit Rated capacity for each indoor unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
COP
(W/W)Room
Total
Room
Min.
Rated
Max. Min.
Rated
Max.
1 2 3 4 5 6 1 2 3 4 5 6
7 14 14 18 — — 53 1.78 3.57 3.57 4.58 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
7 14 14 24 — — 59 1.60 3.20 3.20 5.50 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
7 14 18 18 — — 57 1.66 3.32 4.26 4.26 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
7 18 18 18 — — 61 1.56 3.98 3.98 3.98 — — 3.5 13.5 16.0 0.7 3.56 4.41 3.79
9 9 9 9 — — 36 3.05 3.05 3.05 3.05 — — 3.5 12.2 13.1 0.7 3.09 3.54 3.95
9 9 9 12 — — 39 2.93 2.93 2.93 3.91 — — 3.5 12.7 14.2 0.7 3.35 3.87 3.79
9 9 9 14 — — 41 2.85 2.85 2.85 4.45 — — 3.5 13.0 14.9 0.7 3.46 4.09 3.76
9 9 9 18 — — 45 2.70 2.70 2.70 5.40 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
9 9 9 24 — — 51 2.38 2.38 2.38 6.36 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
9 9 12 12 — — 42 2.83 2.83 3.77 3.77 — — 3.5 13.2 15.3 0.7 3.52 4.20 3.75
9 9 12 14 — — 44 2.76 2.76 3.68 4.30 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
9 9 12 18 — — 48 2.53 2.53 3.38 5.06 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
9 9 12 24 — — 54 2.25 2.25 3.00 6.00 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
9 9 14 14 — — 46 2.64 2.64 4.11 4.11 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
9 9 14 18 — — 50 2.43 2.43 3.78 4.86 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
9 9 14 24 — — 56 2.17 2.17 3.38 5.78 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
9 9 18 18 — — 54 2.25 2.25 4.50 4.50 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
9 9 18 24 — — 60 2.03 2.03 4.05 5.39 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
9 12 12 12 — — 45 2.70 3.60 3.60 3.60 — — 3.5 13.5 16.0 0.7 3.61 4.41 3.74
9 12 12 14 — — 47 2.59 3.45 3.45 4.01 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
9 12 12 18 — — 51 2.38 3.18 3.18 4.76 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
9 12 12 24 — — 57 2.13 2.84 2.84 5.69 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
9 12 14 14 — — 49 2.48 3.30 3.86 3.86 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
9 12 14 18 — — 53 2.29 3.06 3.57 4.58 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
9 12 14 24 — — 59 2.06 2.75 3.20 5.49 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
9 12 18 18 — — 57 2.13 2.85 4.26 4.26 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
9 14 14 14 — — 51 2.37 3.71 3.71 3.71 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
9 14 14 18 — — 55 2.21 3.44 3.44 4.41 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
9 14 14 24 — — 61 1.99 3.10 3.10 5.31 — — 3.5 13.5 16.0 0.7 3.56 4.41 3.79
9 14 18 18 — — 59 2.06 3.20 4.12 4.12 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
12 12 12 12 — — 48 3.38 3.38 3.38 3.38 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
12 12 12 14 — — 50 3.24 3.24 3.24 3.78 — — 3.5 13.5 16.0 0.7 3.60 4.41 3.75
12 12 12 18 — — 54 3.00 3.00 3.00 4.50 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
12 12 12 24 — — 60 2.70 2.70 2.70 5.40 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
12 12 14 14 — — 52 3.12 3.12 3.63 3.63 — — 3.5 13.5 16.0 0.7 3.59 4.41 3.76
12 12 14 18 — — 56 2.89 2.89 3.38 4.34 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
12 12 14 24 — — 62 2.61 2.61 3.05 5.23 — — 3.5 13.5 16.0 0.7 3.56 4.41 3.79
12 12 18 18 — — 60 2.70 2.70 4.05 4.05 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
12 14 14 14 — — 54 3.00 3.50 3.50 3.50 — — 3.5 13.5 16.0 0.7 3.58 4.41 3.77
12 14 14 18 — — 58 2.79 3.26 3.26 4.19 — — 3.5 13.5 16.0 0.7 3.57 4.41 3.78
12 14 18 18 — — 62 2.61 3.05 3.92 3.92 — — 3.5 13.5 16.0 0.7 3.56 4.41 3.79
7 7 7 7 7 — 35 2.40 2.40 2.40 2.40 2.40 — 3.5 12.0 12.7 0.7 2.82 3.44 4.26
7 7 7 7 9 — 37 2.33 2.33 2.33 2.33 2.98 — 3.5 12.3 13.5 0.7 3.03 3.65 4.06
7 7 7 7 12 — 40 2.24 2.24 2.24 2.24 3.84 — 3.5 12.8 14.5 0.7 3.29 3.98 3.89
7 7 7 7 14 — 42 2.20 2.20 2.20 2.20 4.40 — 3.5 13.2 15.3 0.7 3.40 4.20 3.88
7 7 7 7 18 — 46 2.05 2.05 2.05 2.05 5.30 — 3.5 13.5 16.0 0.7 3.49 4.41 3.87
7 7 7 7 24 — 52 1.82 1.82 1.82 1.82 6.22 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 7 7 9 9 — 39 2.28 2.28 2.28 2.93 2.93 — 3.5 12.7 14.2 0.7 3.23 3.87 3.93
7 7 7 9 12 — 42 2.20 2.20 2.20 2.83 3.77 — 3.5 13.2 15.3 0.7 3.40 4.20 3.88
7 7 7 9 14 — 44 2.15 2.15 2.15 2.76 4.29 — 3.5 13.5 16.0 0.7 3.49 4.41 3.87
7 7 7 9 18 — 48 1.97 1.97 1.97 2.53 5.06 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 7 9 24 — 54 1.75 1.75 1.75 2.25 6.00 — 3.5 13.5 16.0 0.7 3.46 4.41 3.90
7 7 7 12 12 — 45 2.10 2.10 2.10 3.60 3.60 — 3.5 13.5 16.0 0.7 3.49 4.41 3.87
7 7 7 12 14 — 47 2.01 2.01 2.01 3.45 4.02 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 7 12 18 — 51 1.85 1.85 1.85 3.18 4.77 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 7 7 12 24 — 57 1.66 1.66 1.66 2.84 5.68 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 7 7 14 14 — 49 1.93 1.93 1.93 3.86 3.86 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 7 14 18 — 53 1.78 1.78 1.78 3.57 4.59 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 7 7 14 24 — 59 1.60 1.60 1.60 3.20 5.50 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 7 7 18 18 — 57 1.66 1.66 1.66 4.26 4.26 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 7 9 9 9 — 41 2.22 2.22 2.85 2.85 2.85 — 3.5 13.0 14.9 0.7 3.34 4.09 3.89
7 7 9 9 12 — 44 2.15 2.15 2.76 2.76 3.68 — 3.5 13.5 16.0 0.7 3.49 4.41 3.87
7 7 9 9 14 — 46 2.05 2.05 2.64 2.64 4.12 — 3.5 13.5 16.0 0.7 3.49 4.41 3.87
7 7 9 9 18 — 50 1.89 1.89 2.43 2.43 4.86 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 9 9 24 — 56 1.69 1.69 2.17 2.17 5.78 — 3.5 13.5 16.0 0.7 3.46 4.41 3.90
7 7 9 12 12 — 47 2.01 2.01 2.58 3.45 3.45 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 9 12 14 — 49 1.93 1.93 2.48 3.31 3.85 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 9 12 18 — 53 1.78 1.78 2.29 3.06 4.59 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 7 9 12 24 — 59 1.60 1.60 2.06 2.75 5.49 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 7 9 14 14 — 51 1.85 1.85 2.38 3.71 3.71 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 7 9 14 18 — 55 1.72 1.72 2.21 3.44 4.41 — 3.5 13.5 16.0 0.7 3.46 4.41 3.90
7 7 9 14 24 — 61 1.55 1.55 1.99 3.10 5.31 — 3.5 13.5 16.0 0.7 3.44 4.41 3.92
7 7 9 18 18 — 59 1.60 1.60 2.06 4.12 4.12 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 7 12 12 12 — 50 1.89 1.89 3.24 3.24 3.24 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 7 12 12 14 — 52 1.82 1.82 3.12 3.12 3.62 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 7 12 12 18 — 56 1.69 1.69 2.89 2.89 4.34 — 3.5 13.5 16.0 0.7 3.46 4.41 3.90
7 7 12 12 24 — 62 1.52 1.52 2.61 2.61 5.24 — 3.5 13.5 16.0 0.7 3.44 4.41 3.92
7 7 12 14 14 — 54 1.75 1.75 3.00 3.50 3.50 — 3.5 13.5 16.0 0.7 3.46 4.41 3.90
7 7 12 14 18 — 58 1.63 1.63 2.79 3.26 4.19 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 7 12 18 18 — 62 1.52 1.52 2.62 3.92 3.92 — 3.5 13.5 16.0 0.7 3.44 4.41 3.92
7 7 14 14 14 — 56 1.68 1.68 3.38 3.38 3.38 — 3.5 13.5 16.0 0.7 3.46 4.41 3.90
7 7 14 14 18 — 60 1.58 1.58 3.15 3.15 4.04 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 9 9 9 9 — 43 2.18 2.78 2.78 2.78 2.78 — 3.5 13.3 15.6 0.7 3.44 4.30 3.87
7 9 9 9 12 — 46 2.05 2.64 2.64 2.64 3.53 — 3.5 13.5 16.0 0.7 3.49 4.41 3.87
7 9 9 9 14 — 48 1.97 2.53 2.53 2.53 3.94 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 9 9 9 18 — 52 1.82 2.34 2.34 2.34 4.66 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
7 9 9 9 24 — 58 1.63 2.09 2.09 2.09 5.60 — 3.5 13.5 16.0 0.7 3.45 4.41 3.91
7 9 9 12 12 — 49 1.92 2.48 2.48 3.31 3.31 — 3.5 13.5 16.0 0.7 3.48 4.41 3.88
7 9 9 12 14 — 51 1.85 2.38 2.38 3.18 3.71 — 3.5 13.5 16.0 0.7 3.47 4.41 3.89
DESIGN & TECHNICAL MANUAL
- 358 -
OUTDOOR UNIT AOYG45LBLA6

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
