Fujitsu ARYG72LHTA User Manual

¢
Heating capacity (Twin)

Cassette type
Model: AUYG36LRLE × 2
AFR
m
3
/h
3,600
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 10.58 5.91 10.32 6.03 10.07 6.16 9.82 6.28 9.57 6.39
-15 -16 16.21 6.82 15.83 6.96 15.44 7.11 15.06 7.25 14.68 7.39
-10 -11 18.89 7.25 18.44 7.40 18.00 7.55 17.55 7.70 17.10 7.85
-5 -7 20.98 7.56 20.48 7.71 19.98 7.87 19.48 8.03 18.99 8.18
0 -2 22.62 7.63 22.08 7.79 21.54 7.95 21.00 8.11 20.47 8.27
5 3 25.56 7.65 24.95 7.81 24.35 7.97 23.73 8.11 23.13 8.27
7 6 25.83 7.66 25.22 7.82 24.60 7.98 23.99 8.14 23.37 8.30
10 8 27.04 7.61 26.39 7.76 25.74 7.93 25.09 8.08 24.46 8.25
15 10 28.06 7.60 27.39 7.75 26.72 7.92 26.05 8.08 25.38 8.20
20 15 25.25 6.64 24.64 6.76 24.04 6.91 23.44 7.05 22.83 7.14
24 18 25.81 6.60 25.19 6.73 24.58 6.87 23.96 7.02 23.35 7.11

Duct type
Model: ARYG36LMLE × 2
AFR
m
3
/h
4,200
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 10.58 5.89 10.32 6.01 10.07 6.14 9.82 6.26 9.57 6.37
-15 -16 16.21 6.80 15.83 6.94 15.44 7.08 15.06 7.22 14.68 7.36
-10 -11 18.89 7.22 18.44 7.37 18.00 7.52 17.55 7.67 17.10 7.82
-5 -7 20.98 7.53 20.48 7.69 19.98 7.84 19.48 8.00 18.99 8.15
0 -2 22.62 7.61 22.08 7.77 21.54 7.92 21.00 8.08 20.47 8.24
5 3 25.56 7.63 24.95 7.79 24.35 7.94 23.73 8.09 23.13 8.25
7 6 25.83 7.63 25.22 7.79 24.60 7.95 23.99 8.11 23.37 8.27
10 8 27.04 7.58 26.39 7.73 25.74 7.90 25.09 8.05 24.46 8.22
15 10 28.06 7.58 27.39 7.73 26.72 7.89 26.05 8.06 25.38 8.17
20 15 25.25 6.61 24.64 6.74 24.04 6.88 23.44 7.03 22.83 7.12
24 18 25.81 6.58 25.19 6.71 24.58 6.85 23.96 6.99 23.35 7.08

Ceiling type
Model: ABYG36LRTE × 2
AFR
m
3
/h
3,800
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC TC
kW kW kW kW kW kW
-20 -21 10.58 5.91 10.32 6.03 10.07 6.16 9.82 6.28 9.57 6.39
-15 -16 16.21 6.82 15.83 6.96 15.44 7.11 15.06 7.25 14.68 7.39
-10 -11 18.89 7.25 18.44 7.40 18.00 7.55 17.55 7.70 17.10 7.85
-5 -7 20.98 7.56 20.48 7.71 19.98 7.87 19.48 8.03 18.99 8.18
0 -2 22.62 7.63 22.08 7.79 21.54 7.95 21.00 8.11 20.47 8.27
5 3 25.56 7.65 24.95 7.81 24.35 7.97 23.73 8.11 23.13 8.27
7 6 25.83 7.66 25.22 7.82 24.60 7.98 23.99 8.14 23.37 8.30
10 8 27.04 7.61 26.39 7.76 25.74 7.93 25.09 8.08 24.46 8.25
15 10 28.06 7.60 27.39 7.75 26.72 7.92 26.05 8.08 25.38 8.20
20 15 25.25 6.64 24.64 6.76 24.04 6.91 23.44 7.05 22.83 7.14
24 18 25.81 6.60 25.19 6.73 24.58 6.87 23.96 7.02 23.35 7.11
- 154 -
6-1. Model: AOYG72LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
