5-6. Active filter module
Check point 1. Check open or short circuit and diode (D1)
Remove connector, check the open or short-circuit and the diode in the module.
Check the open or short-circuit.
L2L1
P
+ (+IN)*
- ( -IN)*
N1 (N)*
LOT No. of PM-601 [FGEL] type
Model name Lot no.(10 figures)
Label position
Label
Table 1. Each type standard value
Terminal
Resistance value
Type A Type B
Multimeter
SACT32010 [HITACHI]
LACT33020 [HITACHI]
PM-604 [FGEL]
PM-703 [FGEL]
(+) (-)
PM-601 [FGEL]
Lot no: —1302931395
PM-601 [FGEL]
Lot no: 1302931396—
+
(+IN)*
- (-IN)* 360 kΩ±20% 360 kΩ±20%
- (-IN)* N1 (N)* 0 Ω 0 Ω
P
+
(+IN)*
720 kΩ±20% 900 kΩ±20%

L1 L2
1.01 MΩ/0.76 MΩ
(Ref. value 1/Ref. value 2)
1.01 MΩ/0.76 MΩ
(Ref. value 1/Ref. value 2)
P N1 (N)* 360 kΩ±20% 540 kΩ±20%
L1, L2
Control
box
∞ Ω ∞ Ω
L2 N1 (N)*
1.65 MΩ/1.14 MΩ
(Ref. value 1/Ref. value 2)
1.65 MΩ/1.14 MΩ
(Ref. value 1/Ref. value 2)

*: () is FGEL terminal name
(Continued)
5-6. Active filter module - (03-81) - 5. Service parts information
