Check point 2
4 Set tester to the diode mode, and measure the voltage value between the following terminals.
5 Judge the result of 4 as follows:
Terminal
Tester screenTester
(+) (-)
P U
∞P V
P W
U P
0.3 to 0.7 V
V P
W P
N U
N V
N W
U N
∞V N
W N
5-7. IPM on transistor PCB - (03-84) - 5. Service parts information
TROUBLESHOOTING TROUBLESHOOTING
