• Special operation
Frequency (rps)
I II III IV
27 42 54 65
Time (sec)
1 2 3 4
60 240 480 660
NOTES:
•
Normal operation:
– Cooling and dry mode
• Below 3 hours from the compressor stop and the compressor thermistor ≥ 32 °C in heating
mode
• After defrost operation
– Other than when the compressor starts for the first time since the breaker turns on
• Special operation:
– Other than the normal operation condition
– When the compressor starts for the first time since the breaker turns on
1-4. Compressor frequency at normal start-up - (04-4) - 1. Compressor frequency control
