Fujitsu ASYA09LEC User Manual

-
(
01 - 11
)
-
WALL MOUNTED TYPE AS

A09-12LE
WALL MOUNTED TYPE AS

A09-12LE
HEATING CAPACITY6-2.
This table is created using the maximum capacity.
MODEL

:
AS

A09LE
MODEL

:
AS

A12LE
AFR : Air flow rate (m
3
/min)
TC : Total capacity (kW)
PI : Power Input (kW)
AFR 12.5
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC PI TC PI TC PI TC PI TC PI
-25 -26 2.88 1.07 2.81 1.09 2.74 1.11 2.68 1.14 2.61 1.16
-20 -21 3.21 1.28 3.13 1.31 3.05 1.34 2.98 1.36 2.90 1.39
-15 -16 3.48 1.50 3.39 1.53 3.31 1.56 3.23 1.59 3.15 1.62
-10 -11 3.75 1.71 3.66 1.75 3.57 1.78 3.48 1.82 3.39 1.85
-5 -7 4.03 1.70 3.94 1.73 3.84 1.77 3.75 1.80 3.65 1.84
0 -2 4.14 1.70 4.04 1.73 3.94 1.77 3.84 1.80 3.74 1.84
5 3 4.64 1.70 4.53 1.73 4.42 1.77 4.31 1.80 4.20 1.84
7 6 5.04 1.70 4.92 1.73 4.80 1.77 4.68 1.80 4.56 1.84
10 8 5.38 1.70 5.25 1.73 5.12 1.77 4.99 1.80 4.87 1.84
15 10 5.69 1.70 5.55 1.73 5.42 1.77 5.28 1.80 5.15 1.84
AFR 12.5
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC PI TC PI TC PI TC PI TC PI
-25 -26 3.07 1.09 3.00 1.12 2.92 1.14 2.85 1.16 2.78 1.18
-20 -21 3.35 1.28 3.27 1.31 3.19 1.34 3.11 1.36 3.03 1.39
-15 -16 3.73 1.47 3.64 1.50 3.56 1.54 3.47 1.57 3.38 1.60
-10 -11 4.22 1.66 4.12 1.70 4.02 1.73 3.92 1.77 3.82 1.80
-5 -7 4.65 1.73 4.54 1.77 4.43 1.80 4.32 1.84 4.20 1.87
0 -2 4.81 1.88 4.69 1.92 4.58 1.96 4.47 2.00 4.35 2.04
5 3 5.64 1.68 5.51 1.71 5.37 1.75 5.24 1.78 5.10 1.82
7 6 5.88 1.70 5.74 1.73 5.60 1.77 5.46 1.80 5.32 1.84
10 8 6.18 1.71 6.03 1.75 5.88 1.78 5.74 1.82 5.59 1.85
15 10 6.42 1.72 6.26 1.75 6.11 1.79 5.96 1.83 5.81 1.86
