02 - 03
)
-
OUTDOOR UNIT
AO
R09-12LE
OUTDOOR UNIT
AO
R09-12LE
REFRIGERANT CIRCUIT3.
MODEL
:AO
R09LE, AO
R12LE
2-Way
valve
Strainer
Strainer
3-Way
valve
Muffler
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
Compressor
Cooling
Heatin
g
Refrigerant pipe diameter
Liquid : 1/4" (6.35 mm)
Gas : 3/8" (9.52 mm)
