WALL MOUNTED TYPE AS

A09-12LE
WALL MOUNTED TYPE AS

A09-12LE
SPECIFICATIONS3.
Note :
Specifications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB/24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB/6 °CWB.
Pipe length : 5 m, Height difference : 0 m.(Outdoor unit - Indoor unit)
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name AS

A09LEC AS

A12LEC
Power source 230V~ 50Hz
Available voltage range 198-264V ~ 50Hz
European energy label
Cooling A A
Heating A A
Capacity
Cooling
Rated
kW 2.50 3.40
BTU/h 8,500 11,600
Min-Max
kW 0.5 - 3.2 0.9 - 3.9
BTU/h 1,700 - 10,900 3,100 - 13,300
Heating
Rated
kW 3.20 4.00
BTU/h 10,900 13,600
Min-Max
kW 0.5 - 4.5 0.9 - 5.6
BTU/h 1,700 - 15,300 3,100 - 19,100
Input power
Cooling
Rated
kW
0.63 0.895
Min-Max 0.25 - 1.27 0.25 - 1.40
Heating
Rated 0.75 0.97
Min-Max 0.25 - 1.60 0.25 - 1.99
Current
Cooling
Rated
A
3.2 4.3
Max 6.0 6.5
Heating
Rated 3.7 4.6
Max 9.5 9.0
EER Cooling
kW/kW
3.97 3.80
COP Heating 4.27 4.12
SENSIBLE CAPACITY Cooling kW 1.60 2.20
POWER FACTOR
Cooling
%
87 91
Heating 89 92
Moisture removal l/h (pints/h) 1.3 ( 2.7 ) 1.8 ( 3.8 )
Fan
Airflow
rate
Cooling
High
m
3
/h
735
Med 595
Low 425
Quiet 285
Heating
High 735
Med 595
Low 425
Quiet 285
Type × Q'ty Cross flow fan×1
Motor output W 30
Sound pressure level
Cooling
High
dB(A)
43
Med 38
Low 33
Quiet 21
Heating
High 43
Med 38
Low 33
Quiet 21
Heat exchanger type
Dimensions
(H × W × D)
mm
256 × 630 × 20
Fin pitch 1.1
Rows x Stages 2 × 16
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour
White
Approximate colour of MUNSELL N 9.25/
Dimensions
( H×W ×D )
Net
mm
260 × 790 × 202
Gross 259 × 840 × 328
Weight
Net
kg(lb.)
7.5 (17)
Gross 9.5 (20)
Connection pipe
Size
Liquid
mm
Φ6.35 (Φ 1/4 in.)
Gas Φ9.52 (Φ 3 /8 in.)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 30 or less
Remote controller type Wireless
Drain pipe
Material PP + LLDPE
Size mm Outer diameter: 21 / Inner diameter: 13.6
