Fujitsu ASYA09LEC User Manual

-
(
02 - 01
)
-
OUTDOOR UNIT AO

R09-12LE
OUTDOOR UNIT AO

R09-12LE
SPECIFICATIONS1.
Note :
Specifications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB/24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB/6 °CWB.
Pipe length : 5 m, Height difference : 0 m.(Outdoor unit - Indoor unit)
Type INVERTER HEAT PUMP
Model name AO

R09LECN AO

R12LECN
Power source 230V~ 50Hz
Available voltage range 198-264V ~ 50Hz
Starting current A 3.7 4.6
Fan
Airflow
rate
Cooling
m
3
/h
2,020 1,950
Heating 1,760 1,700
Type × Q'ty Propeller fan×1
Motor output W 50
Sound pressure level
Cooling
dB(A)
48 49
Heating 47 48
Heat exchanger type
Dimensions
(H × W × D)
mm
508 × 896 × 22 504 × 896 × 18.2
Fin pitch 1.3 1.4
Rows x Stages 1 × 20 2 × 24
Pipe type Copper
Fin type Aluminium
Compressor
Type × Q'ty Rotary ×1
Motor output W 750
Refrigerant
Type R410A
Charge g 950 1,000
Refrigerant oil Type POE(VG74)
Enclosure
Material Steel
Colour
Beige
Approximate colour of MUNSELL 10YR 7.5/1.0
Dimensions
( H×W×D)
Net
mm
540 × 790 × 290
Gross 648 × 910 × 380
Weight
Net
kg(lb.)
33 (72) 36 (79)
Gross 36 (79) 39 (85)
Connection pipe
Size
Liquid
mm
Φ6.35 (Φ 1/4 in.)
Gas Φ9.52 (Φ 3/8 in.)
Method Flare
Max. length
m
20(chargeless:15)
Max. height difference 15
Operation range
Cooling
°C
10 to 43
Heating -25 to 24
