Specifications

Unit: mm

120 21.3

120

Side viewFront view

Size (H × W × D) mm 120 × 120 × 21.3

Weight g 220

 Wiring specifications

Use Cable size Wire type Remarks

Remote controller cable

0.33 mm

Polar 3 core Use sheathed PVC cable.

DESIGN & TECHNICAL MANUAL

- 180 -

MULTI TYPE

5, 6 ROOMS TYPE
