Fujitsu ASYG09LMCA Design & Technical Manual

6-3. Heating capacity
¢ Model: AOYG36LBLA5
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
54
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
53
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
52
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
51
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
50
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
49
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
48
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
47
-15.0
-16.0 10.28 4.30 9.79 4.30 9.40 4.30 9.20 4.29 9.01 4.28
-10.0 -11.0 11.50 4.30 10.96 4.30 10.60 4.30 10.38 4.29 10.15 4.28
-5.0 -7.0 12.78 4.30 12.24 4.30 11.80 4.30 11.62 4.29 11.45 4.28
0.0 -2.0 14.08 4.30 13.54 4.30 13.00 4.30 12.69 4.28 12.37 4.26
5.0 3.0 15.87 4.30 15.12 4.30 14.00 4.30 13.53 4.17 13.07 4.05
7.0 6.0 16.19 4.14 15.23 4.06 14.00 3.98 13.34 3.78 12.69 3.57
10.0 8.0 16.07 4.13 15.12 4.05 14.00 3.97 13.35 3.86 12.70 3.75
15.0 10.0 16.05 4.14 15.02 4.06 14.00 3.94 13.40 3.82 12.80 3.70
20.0 15.0 15.93 3.97 14.92 3.89 14.00 3.78 13.46 3.66 12.91 3.54
24.0 18.0 15.73 3.83 14.82 3.76 14.00 3.65 13.75 3.62 13.51 3.58
DESIGN & TECHNICAL MANUAL
- 302 -
OUTDOOR UNIT AOYG36LBLA5
