3-4. Wall mounted type
¢
Models: ASYG07LMCA, ASYG09LMCA, ASYG12LMCA, and
ASYG14LMCA
Unit: mm
268
(268)
34216
209
74
840 203
(840)
410
310
430
165 144
178 233
321 315
295
Outline of unit
65 for pipe inlet
65 for pipe inlet
DESIGN & TECHNICAL MANUAL
- 30 -
MULTI TYPE
5, 6 ROOMS TYPE
