¢ Floor type
MODEL: AGYG09LVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
-5.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
0.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
5.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
10.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
15.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
20.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
25.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
30.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
35.0 2.10 1.42 2.52 1.73 2.85 1.97 3.22 2.54 3.44 2.78 3.55 3.19
40.0 1.99 1.27 2.39 1.54 2.70 1.76 3.05 2.28 3.26 2.49 3.36 2.85
46.0 1.87 1.13 2.25 1.37 2.55 1.57 2.87 2.03 3.07 2.22 3.17 2.54
MODEL: AGYG12LVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
0.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
5.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
10.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
15.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
20.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
25.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
30.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
35.0 2.80 1.77 3.37 2.16 3.81 2.46 4.30 3.18 4.60 3.48 4.74 3.99
40.0 2.65 1.58 3.19 1.93 3.60 2.20 4.07 2.85 4.35 3.12 4.48 3.57
46.0 2.50 1.41 3.01 1.72 3.40 1.96 3.84 2.53 4.10 2.77 4.23 3.18
MODEL: AGYG14LVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
-5.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
0.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
5.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
10.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
15.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
20.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
25.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
30.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
35.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
40.0 3.09 1.80 3.72 2.19 4.20 2.50 4.74 3.23 5.07 3.53 5.22 4.05
46.0 2.91 1.60 3.51 1.95 3.96 2.22 4.47 2.87 4.78 3.14 4.93 3.60
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
- 301 -
OUTDOOR UNIT AOYG36LBLA5
