7. Press the

button once to transmit the function setting information. 1 short beep will be

emitted from the IR receiver when the signal is received correctly. If wrong code is set, no

beep sound will be emitted.

1 short beep

NOTE:

Press

button within 30 seconds after pressing MODE button.

For the function details, refer to Chapter 14-6. "Function details" on page 241.

8. Exit the function setting mode by pressing the RESET button.

RESET

DESIGN & TECHNICAL MANUAL

- 220 -

MULTI TYPE

5, 6 ROOMS TYPE
