15-6. Floor type

Models: AGYG09LVCA, AGYG12LVCA, and AGYG14LVCA

Part name Exterior Q’ty Part name Exterior Q’ty

Operating manual 1

Remote controller

holder

Installation manual 1 Cloth tape 1

Wall hook bracket 1

Tapping screw (large),

M4 × 25 mm

Remote controller 1

Tapping screw (small),

M3 × 12 mm

Battery 2 Air cleaning filter 2

DESIGN & TECHNICAL MANUAL

- 262 -

MULTI TYPE

5, 6 ROOMS TYPE
