Fujitsu ASYG09LMCA Design & Technical Manual

¢ Wall mounted type
MODELS: ASYG07LMCA, ASYG07LMCE, and ASYG07LUCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
-5.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
0.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
5.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
10.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
15.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
20.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
25.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
30.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
35.0 1.64 1.13 1.97 1.38 2.22 1.57 2.51 2.03 2.68 2.22 2.77 2.55
40.0 1.55 1.01 1.86 1.23 2.10 1.41 2.37 1.82 2.54 1.99 2.62 2.28
46.0 1.46 0.90 1.76 1.10 1.98 1.25 2.24 1.62 2.39 1.77 2.47 2.03
MODELS: ASYG09LMCA, ASYG09LMCE, and ASYG09LUCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
-5.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
0.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
5.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
10.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
15.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
20.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
25.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
30.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
35.0 2.10 1.45 2.52 1.77 2.85 2.02 3.22 2.61 3.44 2.85 3.55 3.27
40.0 1.99 1.30 2.39 1.58 2.70 1.81 3.05 2.34 3.26 2.55 3.36 2.93
46.0 1.87 1.16 2.25 1.41 2.55 1.61 2.87 2.08 3.07 2.27 3.17 2.60
MODELS: ASYG12LMCA, ASYG12LMCE, and ASYG12LUCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
-5.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
0.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
5.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
10.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
15.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
20.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
25.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
30.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
35.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
40.0 2.65 1.63 3.19 1.98 3.60 2.26 4.07 2.93 4.35 3.20 4.48 3.67
46.0 2.50 1.45 3.01 1.76 3.40 2.01 3.84 2.60 4.10 2.85 4.23 3.26
MODELS: ASYG14LMCA, ASYG14LMCE, and ASYG14LUCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
-5.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
0.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
5.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
10.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
15.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
20.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
25.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
30.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
35.0 3.26 2.09 3.93 2.55 4.44 2.90 5.01 3.76 5.36 4.11 5.52 4.71
40.0 3.09 1.87 3.72 2.28 4.20 2.60 4.74 3.36 5.07 3.68 5.22 4.22
46.0 2.91 1.66 3.51 2.03 3.96 2.31 4.47 2.99 4.78 3.27 4.93 3.75
DESIGN & TECHNICAL MANUAL
- 298 -
OUTDOOR UNIT AOYG36LBLA5
