NOTES:

• *1: By using this function, the wiring is automatically corrected according to the piping.

• *2: When correcting the wiring manually, please disconnect the power supply or turn off

the breaker during results display, and then change the wiring manually according to the

obtained test results.

For example, in Example 1, the wirings connected to the terminals B and C is to be ex-

changed manually.

ABCDE F



ABCDE F

5. During results display, press the "CHECK" switch for 3 seconds or more.

After LEDs A to F have lit in turn, all LEDs will light up indicating that the automatic wiring

correction is completed.

(2-blink)

FEDC

MONITOR

ERROR

POWER

MODE

6. Disconnect the power supply or turn off the breaker and wait 10 minutes then turn the power

back on and perform test run.

NOTE: If you do not disconnect the power supply or turn off the breaker, normal operation

is not possible.

Notices:

• If an error occurs during check run it will be suspended. Correct the error and start check run

again.

• After the check run, if automatic wiring correction is carried out, the indoor unit’s position will

be modified to match the piping. (Note that the display of the optional remote controller

changes.)

• If you start check run again after the automatic wiring correction is finished, the modification

will be reset.

- 333 -

OUTDOOR UNIT

AOYG36LBLA5
