Fujitsu ASYG09LMCA Design & Technical Manual

Combination of indoor unit Rated capacity for each indoor unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
EER
(W/W)Room
Total
Room
Min.
Rated
Max. Min.
Rated
Max.
1 2 3 4 5 6 1 2 3 4 5 6
7 9 9 9 9 12 55 1.59 2.05 2.05 2.05 2.05 2.71 3.5 12.5 14.0 0.8 3.50 4.84 3.57
7 9 9 9 9 14 57 1.54 1.97 1.97 1.97 1.97 3.08 3.5 12.5 14.0 0.8 3.49 4.84 3.58
7 9 9 9 12 12 58 1.50 1.94 1.94 1.94 2.59 2.59 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 9 9 9 12 14 60 1.46 1.88 1.88 1.88 2.50 2.90 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 9 9 12 12 12 61 1.44 1.84 1.84 2.46 2.46 2.46 3.5 12.5 14.0 0.8 3.47 4.84 3.60
9 9 9 9 9 9 54 2.08 2.08 2.08 2.08 2.08 2.08 3.5 12.5 14.0 0.8 3.51 4.84 3.56
9 9 9 9 9 12 57 1.97 1.97 1.97 1.97 1.97 2.65 3.5 12.5 14.0 0.8 3.49 4.84 3.58
9 9 9 9 12 12 60 1.88 1.88 1.88 1.88 2.49 2.49 3.5 12.5 14.0 0.8 3.47 4.84 3.60
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h, 24:
24,000 Btu/h
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is up to 62,000 Btu from 34,000 Btu.
DESIGN & TECHNICAL MANUAL
- 356 -
OUTDOOR UNIT AOYG45LBLA6
