¢ Models: ASYG07LMCE, ASYG09LMCE, ASYG12LMCE, and
ASYG14LMCE
Unit: mm
270
(270)
34218
209
74
870 204
(870)
426
310
444
165 144
178 233
321 315
295
Outline of unit
65 for pipe inlet
65 for pipe inlet
DESIGN & TECHNICAL MANUAL
- 32 -
MULTI TYPE
5, 6 ROOMS TYPE
