1. Specifications
Type Inverter heat pump
Model name AOYG09KMCDN AOYG12KMCDN AOYG14KMCDN
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 3.3 4.3 6.2
Fan
Airflow rate
Cooling
m
3
/h
1,770 2,210 2,450
Heating 1,313 1,335 2,330
Type × Q'ty Propeller fan × 1
Motor output W 23 49 49
Sound pressure level *1
Cooling
dB (A)
48 49 49
Heating 43 43 49
Sound power level
Cooling
dB (A)
59 61
Heating 56 59
Heat exchanger type
Dimensions
(H × W × D)
mm
Main1: 504 × 881 × 18.19
Main2: 504 × 851 × 18.19
Main1: 588 × 881 × 18.19
Main2: 588 × 851 × 18.19
Main1: 672 × 881 × 18.19
Main2: 672 × 851 × 18.19
Fin pitch 1.3
Rows × Stages
Main1: 1 × 24
Main2: 1 × 24
Main1: 1 × 28
Main2: 1 × 28
Main1: 1 × 32
Main2: 1 × 32
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment PC Fin
Compressor
Type × Q'ty DC TWIN ROTARY × 1
Motor output W 810 900 1,060
Refrigerant
Type (Global warming potential) R32 (675)
Charge g 850 940 1,120
Refrigerant oil
Type FW68S RmM68AF
Amount
cm
3
350 400
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
542 × 799 × 290 632 × 799 × 290 716 × 820 × 315
Gross 602 × 940 × 375 692 × 940 × 375 776 × 961 × 450
Weight
Net
kg
35
Gross 40
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
-10 to 43
Heating -25 to 24
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
