Fujitsu ASYG12KMCDN User Manual

6-2. Model: AOYG12KMCDN
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.939 0.925
10 — — 0.966 0.947 0.932
7.5 — 0.979 0.970 0.951 0.936
5 0.992 0.983 0.974 0.955 0.939
0 1.000 0.991 0.981 0.963 0.946
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.991 0.981 0.963 0.946
-7.5 - 0.991 0.981 0.963 0.946
-10 - - 0.981 0.963 0.946
-15 - - - 0.963 0.946
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.903 0.887
10 — — 0.952 0.903 0.887
7.5 — 0.976 0.952 0.903 0.887
5 1.000 0.976 0.952 0.903 0.887
0 1.000 0.976 0.952 0.903 0.887
Indoor unit is lower than
outdoor unit *2
-5 0.995 0.971 0.947 0.899 0.883
-7.5 — 0.969 0.945 0.897 0.881
-10 — — 0.942 0.894 0.879
-15 — — — 0.890 0.875
6-3. Model: AOYG14KMCDN
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.939 0.925
10 — — 0.966 0.947 0.932
7.5 — 0.979 0.970 0.951 0.936
5 0.992 0.983 0.974 0.955 0.939
0 1.000 0.991 0.981 0.963 0.946
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.991 0.981 0.963 0.946
-7.5 — 0.991 0.981 0.963 0.946
-10 — — 0.981 0.963 0.946
-15 — — — 0.963 0.946
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.903 0.887
10 — — 0.952 0.903 0.887
7.5 — 0.976 0.952 0.903 0.887
5 1.000 0.976 0.952 0.903 0.887
0 1.000 0.976 0.952 0.903 0.887
Indoor unit is lower than
outdoor unit *2
-5 0.995 0.971 0.947 0.899 0.883
-7.5 — 0.969 0.945 0.897 0.881
-10 — — 0.942 0.894 0.879
-15 — — — 0.890 0.875
- 54 -
6-2. Model: AOYG12KMCDN 6. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOYG09-14KMCDN
OUTDOOR UNIT AOYG09-14KMCDN
