Fujitsu B22W-6 LED User Manual

Importan t notes
• The device must only be operated in landscape mode (0°) and portrait mode (90°). The
control buttons are located in the middle of the bottom of the mon itor in landscape mo de
(0°) and at the left-hand side of th e monitor in portrait mode (90°).
• Store this manual close to the device. If you pass the device on to third
parties, you should pass this manual on with i t.
• We recommend that you place your device on a durable, non-slip surface. In view
of the many different finishes and varnishes used on furniture, it is possible that the
feet of the device may mark th e surface they stand on.
Power cable
Use the supplied power cable only.
Use the following guidelines if it is necessary to replace the original cable set.
• The female/male re ceptacles of the cord set must meet IEC60320/CEE-22 requirements.
• The cable has to be HAR -certified or VDE-certified . The mark HAR or
VDE will appear on the outer sheath.
• For devices which are mounted on a desk or ta ble, type SVT or SJT cable sets may be
used. For devices which sit on the floor, only S JT type cable sets may be used.
• The cable set must be selected according to the rated current for yo ur device.
• If necessary, replace the original power cable with a regular ground ed 3-core mains lead.
Transporting the device
Device,Trans portati onRetransportation
Transport all parts separately in the ir original packaging or in a packaging which
protects them from knocks and jolts, to the new site.
Do not unpack them until all transportation manoeuvres are completed.
If the device is brought from a cold environment into th e room where it will be used,
condensation may occur. Before operating the device, wait until it is absolutely dry
and has reached approximate ly the same temperature as the installation site.
Cleaning the device
Switch of
f the device and unplug the power plug.
Do not cl
ean any interior pa rts yourself, leave this job to a service technician.
Do not us
e a ny cleaning agents that contain abrasives o r may corrod e plastic.
Ensure
that no liquid enters the device.
The display surface of the device is sensitive to pressure and scratches. Clean
it only using a soft, slightly moistened cloth.
The surface of the casing can be cleaned with a dry cloth. If particu larly dirty, use a cloth that
has been moistened in mild domestic detergent and the n carefully wrung out.
8 Fujitsu Technology Solutions
Downloaded from ManualMonitor.com Manuals

Fujitsu B22W-6 LED Specifications

General

3D	No
HD type	-
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewable size diagonal	559 mm
Viewable size, vertical	296 mm
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	474 mm
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 82 kHz
Display brightness (typical)	250 cd/m²
Power requirements	AC 100V - 240V@50-60Hz, AC/DC
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	5
RMS rated power	2 W
Number of speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28 W
Power consumption (PowerSave)	0.3 W
Certification	CE, TÜV GS, GOST, FCC B, cUL, TCO Displays 5.0, ENERGY STAR 5.0
Product color	White
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	110 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
Package weight	8900 g

Weight and Dimensions

Depth (with stand)	180 mm
Height (with stand)	370 mm
Weight (with stand)	7100 g
Depth (without stand)	60 mm
Width (without stand)	508 mm
Height (without stand)	343 mm
Weight (without stand)	4200 g
