Fujitsu B22W-6 LED User Manual

Operation
Adjusting the volume
Call the Audio setting w indow
Volume
Set the volume for playback with the integrated loudspeakers
Mute
Switch the loudspeakers off or on
Setting the colour temperature and colours
Call the Colour setting window
Select the colour temperature
The "warmt h" of the screen colours is set u sing the colour temperature. The
colour temperature is measured in Kelvin (K). You can choose between
sRGB, 6500 K, 7500 K, 9300 K, Native and Custom Colour.
In the user-defined setting you can change the colour ratios of the basic
colours (red, green, blue) as required.
Adjusting the displ
ay of the OSD menu
Calling the OSD Setup adjustment window
Language
Selecting the langu age for the OSD menu
With this function you select the language for the O SD menu.
The defa ult setting is English.
OSD Timeout
Setting the display duration of the OSD m enu
With this function you can select a value from 10 t o 120 seconds.
If the set time expires without a setting be ing made, the O SD menu is
automatically hidden.
OSD Rota tion
With this function you sw itch the OSD menu from portrait mode to landscape
mode and vice versa.
On = The OSD menu is displayed in portrait mode.
Off = The OSD menu is displayed in landscape mode.
Fujitsu Technology Solutions 27
Downloaded from ManualMonitor.com Manuals

Fujitsu B22W-6 LED Specifications

General

3D	No
HD type	-
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewable size diagonal	559 mm
Viewable size, vertical	296 mm
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	474 mm
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 82 kHz
Display brightness (typical)	250 cd/m²
Power requirements	AC 100V - 240V@50-60Hz, AC/DC
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	5
RMS rated power	2 W
Number of speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28 W
Power consumption (PowerSave)	0.3 W
Certification	CE, TÜV GS, GOST, FCC B, cUL, TCO Displays 5.0, ENERGY STAR 5.0
Product color	White
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	110 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
Package weight	8900 g

Weight and Dimensions

Depth (with stand)	180 mm
Height (with stand)	370 mm
Weight (with stand)	7100 g
Depth (without stand)	60 mm
Width (without stand)	508 mm
Height (without stand)	343 mm
Weight (without stand)	4200 g
