Getting started
Mounting the monitor base
Do not remove the l ocking pin until you have secured the base plate on the
monitor and moved it into the operating position.
1
2
► Insert the base plate on the foot (1).
► Secure the base plate with the screw (2).
► Place the monitor in the operating position.
Adjusting height
The height adjustment is fixed in the transport position.
1
2
► To free the fixing, remove the locking
pin on the flange (1).
The h eight of the monitor can be adjusted
by approximately 150 mm.
► Grasp the monitor with both hands on
the right an d left edge of the casing
and move it up or down (2).
14 Fujitsu
