Fujitsu B24W-6 LED User Manual

Yo ur LCD screen ...
Your LCD screen...
has a whole range of useful feature s and functions, e.g.:
• TFT d isplay (Thin Film Transistor; active matrix)
• minimal space requirement
s thanks to slim c asing
• optimum ergonomic characteristics (totally distortion-free, excellent picture
definition and colour purity right into the corners)
• high degree of brightne
ss and good co ntrast
• high resolution (1920 x 1200)
• presentation of u p to 1
6.7 million colours (in conjunction with an appropriate display adapter)
• automatic scanning of horizontal frequencies from 30 to 82 kHz and refresh rates
(vertical frequencies) from 56 to 76 Hz (absolutely flicker-free)
• Digital screen contr
oller with microprocessor for storing 40 different display modes
• freely adjustable colour alignment for matching the screen colours to the
colours of various input and output devices
• convenient opera
tion via integrated OSD (On-Screen-display) menu
• VESA-DDC compatibility
• VESA-FPMPMI com
patibility (Flat Panel Monitor Physical M ounting Interface) –
Mounting de vice
for sw ivel arm and wall bracket
• Plug&Play capability
• Digital video
inputs (D VI and display port DP) with HDCP
• power manag ement for reducing power consumption when th e computer is not in use
• Compliance w
ith the recomm endations according to TCO 5.0
• the monitor fulfills all GS ("Geprüfte Sicherheit", Ce rtified Security) requirements.
This operat
ing manual contains important information you require to start up and run your LCD monitor.
A graphics c
ard (display adapter) with VGA interface or a digital display adapter with DVI interface
or video si
gnal source with DP interface is re quired to control the LCD monitor. The monitor
processes
the data supplied to it by th e display adapter. The display adapter or the associated
driver so
ftware is responsible for setting the modes (resolution and refresh rate).
When putt
ing the monitor into o peration for the first time, the screen display should b e
optimal
ly adapted to the display adapter used and adjusted in acco rdance with your
needs (s
ee cha p ter "
Changing the monitor sett ings", Pag e 20.
Target group
You don’t need to be an "expert" to perform the operations described here.
Nonetheless, it is important to always obse rve the safety notes given in the operating
instructions for th e computer and in this manual.
In the event of any problems, please contact your sales office or our Service Desk.
Fujitsu Technology Solutions 5

Fujitsu B24W-6 LED Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	5
Certification	EN 60950, TÜV GS, GOST, TCO 5.2, FCC B, CE
Product color	Gray
Market positioning	-
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Package weight	8400 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	197 mm
Height (with stand)	395 mm
Depth (without stand)	65 mm
Width (without stand)	559 mm
Height (without stand)	368 mm
Weight (without stand)	6300 g
