Operation
Selecting input signal (D-SUB/DVI-D/HDMI)
► Press the
INPUT
/ buttontocalluptheInput select settings window.
► Press the
ECO
/ or the
INPUT
/ button to select the desired
monitor connection (VG A , DVI or DP).
► Press the
MENU
/ buttontoconfirm your selection or the
AUTO
/ button to cancel the pro cess.
This setting window can also be called u p when the OSD menu is locked.
Locking the OSD menu
The OSD menu can be locked to prevent accidental or unauthorised changes to the monitor settings.
► Press and hold the
MENU
/ button for a few seconds while y ou switch
on the monitor us ing the ON/OFF switch.

The message OSD locked / unlocke d is displayed.
Please p roceed in the same manner to release the locked OSD menu again.
Activate/deactivate ECO operating mode
The pow er consumption of the device can be decreased by redu cing
the brightness of the picture.
► Press the
ECO
/ button t o s witch the ECO operating mode on or o ff.

The message ECO Mode on or ECO Mode off appears.
If the ECO
operating mode is activa ted, the fo llowing OSD settings are changed:
Mode
Office
Colour
6,500 K
Brightness
reduced
After the ECO operating mode is switched off, the brightness previously set by the user is restored.
Fujitsu Technology Solutions 21

Fujitsu B24W-6 LED Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	5
Certification	EN 60950, TÜV GS, GOST, TCO 5.2, FCC B, CE
Product color	Gray
Market positioning	-
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Package weight	8400 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	197 mm
Height (with stand)	395 mm
Depth (without stand)	65 mm
Width (without stand)	559 mm
Height (without stand)	368 mm
Weight (without stand)	6300 g
